Formal Methods

The Isabelle proof assistant includes a small functional language, which allows users to write and reason about programs. So far, these programs could be extracted into a number of functional languages: Standard ML, OCaml, Scala, and Haskell. This work adds support for Go as a fifth target language for the Code Generator. Unlike the previous targets, Go is not a functional language and encourages code in an imperative style, thus many of the features of Isabelle’s language (particularly data types, pattern matching, and type classes) have to be emulated using imperative language constructs in Go. The developed Code Generation is provided as an add-on library that can be simply imported into existing theories.

Small round-off errors in safety-critical systems can lead to catastrophic consequences. In this context, determining if the result computed by a floating-point program is accurate enough with respect to its ideal real-number counterpart is essential. This paper presents PRECiSA 4.0, a tool that rigorously estimates the accumulated round-off error of a floating-point program. PRECiSA 4.0 combines static analysis, optimization techniques, and theorem proving to provide a modular approach for computing a provably correct round-off error estimation. PRECiSA 4.0 adds several features to previous versions of the tool that enhance its applicability and performance. These features include support for data collections such as lists, records, and tuples; support for recursion schemas; an updated floating-point formalization that closely characterizes the IEEE-754 standard; an efficient and modular analysis of function calls that improves the performances for large programs; and a new user interface integrated into Visual Studio Code.

Software is ubiquitous in the digital world, and the correct function of software systems is critical for our society, industry, and infrastructure. While testing and static analysis are long-established techniques in software-development processes, it became widely acknowledged only in the past two decades that formal methods are required for giving guarantees of functional correctness. Both academia and industry worked hard to develop tools for formal verification of software during the past two decades, with the result that many software verifiers are available now (for example, 59 freely available verifiers for C and Java programs). However, most software verifiers are challenging to find, install, and use for both external researchers and potential users. FM-Weck changes this: It provides a fully automatic, zero-configuration container-based setup and execution for more than 50 software verifiers for C and Java. Both the setup requirements and execution parameters of every supported verifier are provided by the tool developers themselves as part of the FM-Tools metadata format that was established recently and was already used by the international competitions SV-COMP and Test-Comp. With our solution FM-Weck, anyone gets fast and easy access to state-of-the-art formal verifiers, no expertise required, fully reproducible.

We propose DFAMiner, a passive learning tool for learning minimal separating deterministic finite automata (DFA) from a set of labelled samples. Separating automata are an interesting class of automata that occurs generally in regular model checking and has raised interest in foundational questions of parity game solving. We first propose a simple and linear-time algorithm that incrementally constructs a three-valued DFA (3DFA) from a set of labelled samples given in the usual lexicographical order. This 3DFA has accepting and rejecting states as well as don’t-care states, so that it can exactly recognise the labelled examples. We then apply our tool to mining a minimal separating DFA for the labelled samples by minimising the constructed automata via a reduction to SAT solving. Empirical evaluation shows that our tool outperforms current state-of-the-art tools significantly on standard benchmarks for learning minimal separating DFAs from samples. Progress in the efficient construction of separating DFAs can also lead to finding the lower bound of parity game solving, where we show that DFAMiner can create optimal separating automata for simple languages with up to 7 colours. Future improvements might offer inroads to better data structures.

Hyperproperties relate multiple executions of a system and are commonly used to specify security and information-flow policies. While many verification approaches for hyperproperties exist, providing a convincing certificate that the system satisfies a given property is still a major challenge. In this paper, we propose strategies as a suitable form of certificate for hyperproperties specified in a fragment of the temporal logic HyperLTL. Concretely, we interpret the verification of a HyperLTL property as a game between universal and existential quantification, allowing us to leverage strategies for the existential quantifiers as certificates. We present HyGaViz, a browser-based visualization tool that lets users interactively explore an (automatically synthesized) witness strategy by taking control over universally quantified executions.

Tools that manipulate OCaml code can sometimes fail even on correct programs. Identifying and understanding the cause of the error usually involves manually reducing the size of the program, so as to obtain a shorter program causing the same error—a long, sometimes complex and rarely interesting task. Our work consists in automating this task using a minimiser, or delta-debugger. To do so, we propose a list of unitary heuristics, i.e. small-scale reductions, applied through a dichotomy-based state-of-the-art algorithm. These proposals are implemented in the free Chamelon tool. Although designed to assist the development of an OCaml compiler, Chamelon can be adapted to all kinds of projects that manipulate OCaml code. It can analyse multifile projects and efficiently minimise real-world programs, reducing their size by one to several orders of magnitude. It is currently used to assist the industrial development of the flambda2 optimising compiler.

We present , a bounded to statically analyse Quality of Service ( ) properties of message-passing systems. We consider QoS properties on measurable application-level attributes as well as resource consumption metrics, for example, those relating monetary cost to memory usage. The applicability of is evaluated through case studies and experiments. A first case study is based on the AWS cloud while a second one analyses a communicating system automatically extracted from code. Additionally, we consider synthetically generated experiments to assess the scalability of . These experiments showed that our model can faithfully capture and effectively analyse QoS properties in industrial-strength scenarios.

Platforms to support novices learning to program are often accompanied by automated next-step hints that guide them towards correct solutions. Many of those approaches are data-driven, building on historical data to generate higher quality hints. Formal specifications are increasingly relevant in software engineering activities, but very little support exists to help novices while learning. Alloy is a formal specification language often used in courses on formal software development methods, and a platform—Alloy4Fun—has been proposed to support autonomous learning. While non-data-driven specification repair techniques have been proposed for Alloy that could be leveraged to generate next-step hints, no data-driven hint generation approach has been proposed so far. This paper presents the first data-driven hint generation technique for Alloy and its implementation as an extension to Alloy4Fun, being based on the data collected by that platform. This historical data is processed into graphs that capture past students’ progress while solving specification challenges. Hint generation can be customized with policies that take into consideration diverse factors, such as the popularity of paths in those graphs successfully traversed by previous students. Our evaluation shows that the performance of this new technique is competitive with non-data-driven repair techniques. To assess the quality of the hints, and help select the most appropriate hint generation policy, we conducted a survey with experienced Alloy instructors.

We present a new SAT backend for the B-Method to enable new applications of formal methods. The new backend interleaves low-level SAT solving with high-level constraint solving. It provides a “bare metal” access to SAT solving, while pre- and post-calculations can be done in the full B language, with access to higher-order or even infinite data values. The backend is integrated into ProB, not as a general purpose backend, but as a dedicated backend for solving hard constraint satisfaction and optimisation problems on complex data. In the article we present the approach, its origin in the proof of Cook’s theorem, and illustrate and evaluate it on a few novel applications of formal methods, ranging from biology to railway applications.

We present PyBDR, a Python reachability analysis toolkit based on set-boundary analysis, which centralizes on widely-adopted set propagation techniques for formal verification, controller synthesis, state estimation, etc. It employs boundary analysis of initial sets to mitigate the wrapping effect during computations, thus improving the performance of reachability analysis algorithms without significantly increasing computational costs. Beyond offering various set representations such as polytopes and zonotopes, our toolkit particularly excels in interval arithmetic by extending operations to the tensor level, enabling efficient parallel interval arithmetic computation and unifying vector and matrix intervals into a single framework. Furthermore, it features symbolic computation of derivatives of arbitrary order and evaluates them as real or interval-valued functions, which is essential for approximating behaviours of nonlinear systems at specific time instants. Its modular architecture design offers a series of building blocks that facilitate the prototype development of reachability analysis algorithms. Comparative studies showcase its strengths in handling verification tasks with large initial sets or long time horizons. The toolkit is available at https://github.com/ASAG-ISCAS/PyBDR .

Multiparty session typing (MPST) is a formal method to make concurrent programming simpler. The idea is to use type checking to automatically prove safety (protocol compliance) and liveness (communication deadlock freedom) of implementations relative to specifications. Discourje is an existing run-time verification library for communication protocols in Clojure, based on dynamic MPST. The original version of Discourje can detect only safety violations. In this paper, we present an extension of Discourje to detect also liveness violations.

Industry is shifting towards service-based business models, for which user satisfaction is crucial. User satisfaction can be analyzed with user journeys, which model services from the user’s perspective. Today, these models are created manually and lack both formalization and tool-supported analysis. This limits their applicability to complex services with many users. Our goal is to overcome these limitations by automated model generation and formal analyses, enabling the analysis of user journeys for complex services and thousands of users. In this paper, we use stochastic games to model and analyze user journeys. Stochastic games can be automatically constructed from event logs and model checked to, e.g., identify interactions that most effectively help users reach their goal. Since the learned models may get large, we use property-preserving model reduction to visualize users’ pain points to convey information to business stakeholders. The applicability of the proposed method is here demonstrated on two complementary case studies.

Fault injection attack is a class of active, physical attacks against cryptographic circuits. The design and implementation of countermeasures against such attacks are intricate, error-prone and laborious, necessitating formal verification to guarantee their correctness. In this paper, we propose the first compositional verification approach for round-based hardware implementations of cryptographic algorithms. Our approach decomposes a circuit into a set of single-round sub-circuits which are verified individually by either SAT/SMT- or BDD-based tools. Our approach is implemented as an open-source tool CLEAVE, which is evaluated extensively on realistic cryptographic circuit benchmarks. The experimental results show that our approach is significantly more effective and efficient than the state-of-the-art.

Autonomous hybrid systems are systems that combine discrete and continuous behavior with autonomous decision-making, e.g., using reinforcement learning. Such systems are increasingly used in safety-critical applications such as self-driving cars, autonomous robots or water supply systems. Thus, it is crucial to ensure their safety and resilience, i.e., that they function correctly even in the presence of dynamic changes and disruptions. In this paper, we present an approach to obtain formal resilience guarantees for autonomous hybrid systems using the interactive theorem prover KeYmaera X. Our key ideas are threefold: First, we derive a formalization of resilience that is tailored to autonomous hybrid systems. Second, we present reusable patterns for modeling stressors, detecting disruptions, and specifying resilience as a service level response in the differential dynamic logic (d $$\mathcal {L}$$ L ). Third, we combine these concepts with an existing approach for the safe integration of learning components using hybrid contracts, and extend it towards dynamic adaptations to stressors. By combining reusable patterns for stressors, observers, and adaptation contracts for learning components, we provide a systematic approach for the deductive verification of resilience of autonomous hybrid systems with reduced specification effort. We demonstrate the applicability of our approach with two case studies, an autonomous robot and an intelligent water distribution system.

Switching controllers play a pivotal role in directing hybrid systems (HSs) towards the desired objective, embodying a “correct-by-construction” approach to HS design. Identifying these objectives is thus crucial for the synthesis of effective switching controllers. While most of existing works focus on safety and liveness, few of them consider timing constraints. In this paper, we delves into the synthesis of switching controllers for HSs that meet system objectives given by a fragment of STL, which essentially corresponds to a reach-avoid problem with timing constraints. Our approach involves iteratively computing the state sets that can be driven to satisfy the reach-avoid specification with timing constraints. This technique supports to create switching controllers for both constant and non-constant HSs. We validate our method’s soundness, and confirm its relative completeness for a certain subclass of HSs. Experiment results affirms the efficacy of our approach.

Barrier certificates, serving as differential invariants that witness system safety, play a crucial role in the verification of cyber-physical systems (CPS). Prevailing computational methods for synthesizing barrier certificates are based on semidefinite programming (SDP) by exploiting Putinar Positivstellensatz. Consequently, these approaches are limited by the Archimedean condition, which requires all variables to be bounded, i.e., systems are defined over bounded domains. For systems over unbounded domains, unfortunately, existing methods become incomplete and may fail to identify potential barrier certificates.In this paper, we address this limitation for the unbounded cases. We first give a complete characterization of polynomial barrier certificates by using homogenization, a recent technique in the optimization community to reduce an unbounded optimization problem to a bounded one. Furthermore, motivated by this formulation, we introduce the definition of homogenized systems and propose a complete characterization of a family of non-polynomial barrier certificates with more expressive power. Experimental results demonstrate that our two approaches are more effective while maintaining a comparable level of efficiency.

Cyber-physical systems (CPS) with reinforcement learning (RL)-based controllers are increasingly being deployed in complex physical environments such as autonomous vehicles, the Internet-of-Things (IoT), and smart cities. An important property of a CPS is tolerance; i.e., its ability to function safely under possible disturbances and uncertainties in the actual operation. In this paper, we introduce a new, expressive notion of tolerance that describes how well a controller is capable of satisfying a desired system requirement, specified using Signal Temporal Logic (STL), under possible deviations in the system. Based on this definition, we propose a novel analysis problem, called the tolerance falsification problem, which involves finding small deviations that result in a violation of the given requirement. We present a novel, two-layer simulation-based analysis framework and a novel search heuristic for finding small tolerance violations. To evaluate our approach, we construct a set of benchmark problems where system parameters can be configured to represent different types of uncertainties and disturbances in the system. Our evaluation shows that our falsification approach and heuristic can effectively find small tolerance violations.

In this paper, we present a tool for monitoring the traces of cyber-physical systems (CPS) at runtime, with respect to Signal Temporal Logic (STL) specifications. Our tool is based on the recent advances of causation monitoring, which reports not only whether an executing trace violates the specification, but also how relevant the increment of the trace at each instant is to the specification violation. In this way, it can deliver more information about system evolution than classic online robust monitors. Moreover, by adapting two dynamic programming strategies, our implementation significantly improves the efficiency of causation monitoring, allowing its deployment in practice. The tool is implemented as a C++ executable and can be easily adapted to monitor CPS in different formalisms. We evaluate the efficiency of the proposed monitoring tool, and demonstrate its superiority over existing robust monitors in terms of the information it can deliver about system evolution.

Rust has gained popularity as a safer alternative to C/C++ for low-level programming due to its memory-safety features and minimal runtime overhead. However, the use of the “unsafe” keyword allows developers to bypass safety guarantees, posing memory-safety risks. Bounded Model Checking (BMC) is commonly used to detect memory-safety problems, but it has limitations for large-scale programs, as it can only detect bugs within a bounded number of executions.In this paper, we introduce UnsafeCop that utilizes and enhances BMC for analyzing memory safety in real-world unsafe Rust code. Our methodology incorporates harness design, loop bound inference, and both loop and function stubbing for comprehensive analysis. We optimize verification efficiency through a strategic function verification order, leveraging both types of stubbing. We conducted a case study on TECC (Trusted-Environment-based Cryptographic Computing), a proprietary framework consisting of 30,174 lines of Rust code, including 3,019 lines of unsafe Rust code, developed by Ant Group. Experimental results demonstrate that UnsafeCop effectively detects and verifies dozens of memory safety issues, reducing verification time by 73.71% compared to the traditional non-stubbing approach, highlighting its practical effectiveness.

High-concurrency systems often suffer from performance bottlenecks [1]. This is often caused by waiting and context switching caused by fierce competition between threads for locks. As a cloud computing company, we place great emphasis on maximizing performance. In this regard, we transform the lightweight spin-lock and propose a concise parameter fine-tuning strategy, which can break through the system performance bottleneck with minimal risk conditions. This strategy has been validated in Apache RocketMQ [2], a high-throughput message queue system. Through this strategy, we achieved performance improvements of up to 37.58% on X86 CPU and up to 32.82% on ARM CPU. Furthermore, we confirmed the method’s consistent effectiveness across different code versions and IO flush strategies, demonstrating its broad applicability in real-world settings. This work offers not only a practical tool for addressing performance issues in high-concurrency systems but also highlights the practical value of formal techniques in solving engineering problems.

SCADE is both a formal language and a model-based development environment, widely used to build and verify the models of safety-critical system (SCS). The SCADE Design Verifier (DV) provides SAT-based verification. However, DV cannot adequately express complex temporal specifications, and it may fail due to complexity problems such as floating numbers which are often used in the aeronautics domain. In addition, manually writing temporal specifications is not only time-consuming but also error-prone. To address these challenges, we propose an AGVTS method that can automate the task of generating temporal specifications and verifying aeronautics SCADE models. At first, we define a modular pattern language for precisely expressing Chinese natural language requirements. Then, we present a rule-based translation augmented with BERT, which translates restricted requirements into LTL and CTL. In addition, SCADE model verification is achieved by transforming it into nuXmv which supports both SMT-based and SAT-based verification. Finally, we illustrate a successful application of our methodology with an ejection seat control system, and convince our industrial partners of the usefulness of formal methods for industrial systems.

The formal safety analysis of automated driving vehicles poses unique challenges due to their dynamic operating conditions and significant complexity. This paper presents a case study of applying formal safety verification to adaptive cruise controllers. Unlike the majority of existing verification approaches in the automotive domain, which only analyze (potentially imperfect) controller models, employ simulation to find counter-examples or use online monitors for runtime verification, our method verifies controllers at code level by utilizing bounded model checking. Verification is performed against an invariant set derived from formal specifications and an analytical model of the required behavior. For neural network controllers, we propose a scalable three-step decomposition, which additionally uses a neural network verifier. We show that both traditionally implemented as well as neural network controllers are verified within minutes. The dual focus on formal safety and implementation verification provides a comprehensive framework applicable to similar cyber-physical systems.

In the field of communication system products, most datapath Digital Signal Processing algorithms are initially developed at a high-level in MATLAB® or C/C++. Subsequently, design engineers use these models as a reference for implementing Register Transfer Level designs. The conventional approach to verify their equivalence involves extensive Universal Verification Methodology dynamic simulations, which can last for months and require significant verification efforts. However, some elusive errors might still occur because it is infeasible to explore all input combinations with this method. On the other hand, Formal Equivalence Verification aims to verify that a Register Transfer Level design is functionally equivalent to the reference high-level C/C++ model across all possible legal states. With recent advancements in formal solver technology, Formal Equivalence Verification provides a distinct benefit by using mathematical methods to ensure that the Register Transfer Level (timed) matches the original high-level C/C++ model (untimed). This drastically reduces the verification time and ensures the exhaustive coverage of the design state space. This paper presents an in-depth exploration of complex Finite State Machine with datapath verification, specifically focusing on Multiplier-Accumulator, Tone Generator, and Automatic Gain Control, by employing the formal equivalence methodology. Although these signal processing blocks were previously verified throughout Universal Verification Methodology dynamic simulations, Formal Equivalence Verification was able to identify hard-to-find bugs in just a few weeks by utilizing the new workflow, thereby streamlining the verification process.

Over the past few years there has been significant progress in the various fields of software verification resulting in many useful tools and successful deployments, both academic and commercial. However much of the work describing these tools and ideas is written by and for the research community. The scale, diversity and focus of the literature can act as a barrier, separating industrial users and the wider academic community from the tools that could make their work more efficient, more certain and more productive. This tutorial gives a simple classification of verification techniques in terms of a pyramid and uses it to describe the six main schools of verification technologies. We have found this approach valuable for building collaborations with industry as it allows us to explain the intrinsic strengths and weaknesses of techniques and pick the right tool for any given industrial application. The model also highlights some of the cultural differences and unspoken assumptions of different areas of verification and illuminates future directions.

This tutorial introduces quantum computing with a focus on the applicability of formal methods in this relatively new domain. We describe quantum circuits and convey an understanding of their inherent combinatorial nature and the exponential blow-up that makes them hard to analyze. Then, we show how weighted model counting (#SAT) can be used to solve hard analysis tasks for quantum circuits.This tutorial is aimed at everyone in the formal methods community with an interest in quantum computing. Familiarity with quantum computing is not required, but basic linear algebra knowledge (particularly matrix multiplication and basis vectors) is a prerequisite. The goal of the tutorial is to inspire the community to advance the development of quantum computing with formal methods.

The aim of this tutorial is to explain to the formal methods community the area of risk management and its most prominent concepts: the definition of risk, strategies for managing risk, the risk management cycle, and the role of ISO standards.For each of these concepts, I explain how formal methods relate and contribute, making risk management more accountable: systematic, transparent, and quantitative. I will also argue that viewing Formal Methods through the lens of risk management, and making the relevance of formal methods in risk analysis explicit, helps our community to better communicate the merits of formal methods to industry.

Ultra-critical systems require high-level assurance, which cannot always be guaranteed at compile time. The use of runtime verification (RV) enables monitoring of these systems during runtime, to detect illegal states early and limit their potential consequences. This paper is a tutorial on RV using Copilot, an open-source runtime verification framework actively used by NASA to carry out experiments with robots and unmanned aerial vehicles. Copilot monitors are written in a compositional, stream-based language, which the framework automatically translates into real-time C code that satisfies static memory requirements suitable to run on embedded hardware. Copilot includes multiple libraries that extend the core functionality with higher-level constructs, Boyer-Moore majority voting, and a variety of Temporal Logics (TL), resulting in robust, high-level specifications that are easier to understand than their traditional counterparts.

This tutorial paper introduces ASMETA, a comprehensive suite of integrated tools around the formal method Abstract State Machines to specify and analyze the executable behavior of discrete event systems. ASMETA supports the entire system development life-cycle, from the specification of the functional requirements to the implementation of the code, in a systematic and incremental way. This tutorial provides an overview of ASMETA through an illustrative case study, the Pill-Box, related to the design of a smart pillbox device. It illustrates the practical use of the range of modeling and V&V techniques available in ASMETA and C++ code generation from models, to increase the quality and reliability of behavioral system models and source code.

In this paper, we provide a comprehensive, hands-on tutorial on how to apply deductive verification to programs written in OCaml. In particular, we show how one can use the GOSPEL specification language and the Cameleer tool to conduct mostly-automated verification on OCaml code. In our presentation, we focus on two main classes of programs: first, purely functional programs with no mutable state; then on imperative programs, where one can mix mutable state with subtle control-flow primitives, such as locally-defined exceptions.

This tutorial provides an introduction to CPAchecker for users. CPAchecker is a flexible and configurable framework for software verification and testing. The framework provides many abstract domains, such as BDDs, explicit values, intervals, memory graphs, and predicates, and many program-analysis and model-checking algorithms, such as abstract interpretation, bounded model checking, Impact, interpolation-based model checking, k-induction, PDR, predicate abstraction, and symbolic execution. This tutorial presents basic use cases for CPAchecker in formal software verification, focusing on its main verification techniques with their strengths and weaknesses. An extended version also shows further use cases of CPAchecker for test-case generation and witness-based result validation. The envisioned readers are assumed to possess a background in automatic formal verification and program analysis, but prior knowledge of CPAchecker is not required. This tutorial and user guide is based on CPAchecker in version 3.0. This user guide’s latest version and other documentation are available at https://cpachecker.sosy-lab.org/doc.php .

Great minds have long dreamed of creating machines that can function as general-purpose problem solvers. Satisfiability modulo theories (SMT) has emerged as one pragmatic realization of this dream, providing significant expressive power and automation. This tutorial is a beginner’s guide to SMT. It includes an overview of SMT and its formal foundations, a catalog of the main theories used in SMT solvers, and illustrations of how to obtain models and proofs. Throughout the tutorial, examples and exercises are provided as hands-on activities for the reader. They can be run using either Python or the SMT-LIB language, using either the cvc5 or the Z3 SMT solver.

The KeY tool is a state-of-the-art deductive program verifier for the Java language. Its verification engine is based on a sequent calculus for dynamic logic, realizing forward symbolic execution of the target program, whereby all symbolic paths through a program are explored. Method contracts make verification scalable. KeY combines auto-active and fine-grained proof interaction, which is possible both at the level of the verification target and its specification, as well as at the level of proof rules and program logic. This makes KeY well-suited for teaching program verification, but also permits proof debugging at the source code level. The latter made it possible to verify some of the most complex Java code to date. The article provides a self-contained introduction to the working principles and the practical usage of KeY for anyone with basic knowledge in logic and formal methods.

Stream-based runtime monitoring frameworks are safety assurance tools that check the runtime behavior of a system against a formal specification. This tutorial provides a hands-on introduction to RTLola, a real-time monitoring toolkit for cyber-physical systems and networks. RTLola processes, evaluates, and aggregates streams of input data, such as sensor readings, and provides a real-time analysis in the form of comprehensive statistics and logical assessments of the system’s health. RTLola has been applied successfully in monitoring autonomous systems such as unmanned aircraft. The tutorial guides the reader through the development of a stream-based specification for an autonomous drone observing other flying objects in its flight path. Each tutorial section provides an intuitive introduction, highlighting useful language features and specification patterns, and gives a more in-depth explanation of technical details for the advanced reader. Finally, we discuss how runtime monitors generated from RTLola specifications can be integrated into a variety of systems and discuss different monitoring applications.
