Über dieses Buch

Dieses Buch widmet sich der Blitzübertragung und dem Schutz erneuerbarer Energiesysteme, einschließlich Wind- und Sonnenenergie. Neben dem Entstehungsmechanismus von Blitzübergängen wurde auch die praktische technische Anwendung angesprochen. Dieses Buch ist umfassend und behandelt die Methodik der elektromagnetischen transienten Modellierung, elektromagnetischen Kopplung für PV-Anlagen, Blitzschutzkonstruktion, Prüfung und Bewertung. Dieses Buch eignet sich besonders für Leser, die sich für Blitzphänomene und erneuerbare Energiesysteme interessieren. Davon würden Forscher, Ingenieure und Doktoranden in den Bereichen Elektrotechnik, erneuerbare Energien, Computerelektromagnetismus usw. profitieren.
Mit KI übersetzt

Inhaltsverzeichnis

Frontmatter

Lightning Electromagnetic (EM) Transients and Protection for Photovoltaic System

Frontmatter
Chapter 1. Introduction to Photovoltaic System
Abstract
The photovoltaic (PV) power generation system is mainly composed of large-area PV panels, direct current (DC) combiner boxes, DC distribution cabinets, PV inverters, alternating current (AC) distribution cabinets, grid connected transformers, and connecting cables. Since the output voltage of single PV cell is very small, multiple PV cells are often connected in series through a foil-plated thin copper wire in order to obtain a higher output voltage.
Qiuqin Sun, Li Zhang, Xiao Zhong, Feng Bin, Zhi Zheng
Chapter 2. Mechanism of Lightning Electromagnetic Coupling for Photovoltaic Array
Abstract
The metal frame is (Ahmad et al. in Renew Sust Energ Rev 82:1611–1619, 2018) generally grounded to reduce the induced overvoltage caused by direct and indirect lightning electromagnetic fields. The PV panel is installed on a bracket structure with a slant angle, as depicted in Fig. 2.1. The PV array is boosted up to 35 kV by a DC/AC inverter, and then collected by a cable to substation. It would be further enhanced to 220 kV to power grid.
Qiuqin Sun, Li Zhang, Xiao Zhong, Feng Bin, Zhi Zheng
Chapter 3. Lightning Induced Voltage of Photovoltaic Array on Complex Terrains
Abstract
Suppose a PV array installed on flat ground, twenty PV individual panels are connected into a group, and eight groups are wired together and then linked to the inverter, as shown in Fig. 3.1a. Considering the lightning channel is vertical and perpendicular to the ground, the horizontal distance R, from PV array to the lightning channel, is 5 m. The detailed dimension of single PV panel is depicted in Fig. 3.1b.
Qiuqin Sun, Li Zhang, Xiao Zhong, Feng Bin, Zhi Zheng
Chapter 4. Novel Crossover Wiring of DC Cable for Photovoltaic Array Against Lightning Induced Overvoltage
Abstract
The lightning current will produce a strong EM radiation, and an impulse voltage will be induced in the DC cable around. The associated electronic device like the bypass diode and inverter, as illustrated in Fig. 4.1, may be damaged. The computational model for induced voltages is presented as follows.
Qiuqin Sun, Li Zhang, Xiao Zhong, Feng Bin, Zhi Zheng
Chapter 5. Novel Solar-Cell String Wiring of Photovoltaic Module for Reducing Lightning Induced Overvoltage
Abstract
One solar cell only can provide a very low voltage in full sunlight. To obtain a larger output voltage, tens of solar cells encapsulated inside a PV module are connected in series.
Qiuqin Sun, Li Zhang, Xiao Zhong, Feng Bin, Zhi Zheng
Chapter 6. Effect of Eddy Current for Photovoltaic Module Generated by Lightning Electromagnetic Field
Abstract
A PV module is encapsulated with metal frame, cover glass and waterproof backsheet to prevent the oxidation of solar cells. The lightning EM field will produce an impulse voltage on the PV module, and can damage the bypass diodes in the junction box.
Qiuqin Sun, Li Zhang, Xiao Zhong, Feng Bin, Zhi Zheng

Lightning Electromagnetic (EM) Transients and Protection for Wind Turbines

Frontmatter
Chapter 7. Introduction to Wind Power
Abstract
Wind power has become the most mature and scalable form of renewable energy generation in the world today, with significant prospects for commercial development. Vigorous development of wind power is not only strategically important for energy security and diversification but will also play an increasingly crucial role in addressing climate change and promoting energy efficiency.
Qiuqin Sun, Li Zhang, Xiao Zhong, Feng Bin, Zhi Zheng
Chapter 8. Evaluation of Lightning Strike Distance of Wind Turbine Blades
Abstract
The electrical geometric method establishes a connection between lightning current parameters and the geometric structure of the object under study. It utilizes the concept of striking distance to describe the object’s ability to attract lightning from the ground. According to this method, the lightning leader that reaches the striking distance of a particular object first will discharge towards that object.
Qiuqin Sun, Li Zhang, Xiao Zhong, Feng Bin, Zhi Zheng
Chapter 9. Lightning Protection Efficiency and Shielding for Wind Turbine Blades
Abstract
Nowadays, there are two main types of lightning arresters for wind turbine blades: one is to set the blade tip lightning arrester only at the tip of the blade, and the other is to set the blade tip lightning arrester and the blade body lightning arrester at the same time. However, there is no unified guidance plan for the selection of blade lightning arresters and the arrangement of lightning arresters by various blade manufacturers today. The influence mechanism of the arrangement of lightning arresters on the lightning protection efficiency of blades is still unclear. Therefore, finding a method to characterize the efficiency of the wind turbine blade lightning protection system is the theoretical basis for optimizing the wind turbine blade lightning protection system.
Qiuqin Sun, Li Zhang, Xiao Zhong, Feng Bin, Zhi Zheng
Chapter 10. Damage Mechanism for Wind Turbine Blade Under the Effect of Electric Arc
Abstract
Molecular dynamics simulation is an important research method for studying the structure and properties of molecules or molecular systems through computer simulation. It includes methods such as molecular mechanics, Monte Carlo simulation, and molecular dynamics simulation.
Qiuqin Sun, Li Zhang, Xiao Zhong, Feng Bin, Zhi Zheng
Chapter 11. Lightning Electromagnetic Interference to Electronics Inside Offshore Wind Turbines
Abstract
The design of the offshore wind turbine grounding system is different from that of traditional onshore WTs. The pipe rack structure is used as the foundation of offshore WTs. Considering the economy and the ease of construction, the general engineering uses the foundation as the natural grounding body.
Qiuqin Sun, Li Zhang, Xiao Zhong, Feng Bin, Zhi Zheng
