Runtime Verification

The Monitoring and Checking (MaC) project gave rise to a framework for runtime monitoring with respect to formally specified properties, which later came to be known as runtime verification. The project also built a pioneering runtime verification tool, Java-MaC, that was an instantiation of the approach to check properties of Java programs. In this retrospective, we discuss decisions made in the design of the framework and summarize lessons learned in the course of the project.

Logical specifications have enabled formal methods by carefully describing what is correct, desired or expected of a given system. They have been widely used in runtime monitoring and applied to domains ranging from medical devices to information security. In this tutorial, we will present the theory and application of robustness of logical specifications. Rather than evaluate logical formulas to Boolean valuations, robustness interpretations attempt to provide numerical valuations that provide degrees of satisfaction, in addition to true/false valuations to models. Such a valuation can help us distinguish between behaviors that “barely” satisfy a specification to those that satisfy it in a robust manner. We will present and compare various notions of robustness in this tutorial, centered primarily around applications to safety-critical Cyber-Physical Systems (CPS). We will also present key ways in which the robustness notions can be applied to problems such as runtime monitoring, falsification search for finding counterexamples, and mining design parameters for synthesis.

Runtime enforcement refers to the theories, techniques, and tools for enforcing correct behavior of systems at runtime. We are interested in such behaviors described by specifications that feature timing constraints formalized in what is generally referred to as timed properties. This tutorial presents a gentle introduction to runtime enforcement (of timed properties). First, we present a taxonomy of the main principles and concepts involved in runtime enforcement. Then, we give a brief overview of a line of research on theoretical runtime enforcement where timed properties are described by timed automata and feature uncontrollable events. Then, we mention some tools capable of runtime enforcement, and we present the TiPEX tool dedicated to timed properties. Finally, we present some open challenges and avenues for future work.

Hyperproperties relate multiple computation traces to each other and thus pose a serious challenge to monitoring algorithms. Observational determinism, for example, is a hyperproperty which states that private data should not influence the observable behavior of a system. Standard trace monitoring techniques are not applicable to such properties. In this tutorial, we summarize recent algorithmic advances in monitoring hyperproperties from logical specifications. We classify current approaches into two classes: combinatorial approaches and constraint-based approaches. We summarize current optimization techniques for keeping the execution trace storage and algorithmic workload as low as possible and also report on experiments run on the combinatorial as well as the constraint-based monitoring algorithms.

In stream-based runtime monitoring, streams of data, called input streams, which involve data collected from the system at runtime, are translated into new streams of data, called output streams, which define statistical measures and verdicts on the system based on the input data. The advantage of this setup is an easy-to-use and modular way for specifying monitors with rich verdicts, provided with formal guarantees on the complexity of the monitor.

To demonstrate the expressive power of the different classes of stream specification languages and the complexity of the different features, we use a series of examples based on our experience with monitoring problems from the areas of unmanned aerial systems and telecommunication networks.

Predictive runtime verification estimates the probability of a future event by monitoring the executions of a system. In this paper we use Discrete-Time Markov Chains (DTMC) as predictive models that are trained from many execution samples demonstrating a rare event: an event that occurs with very low probability. More specifically, we propose a method of grammar inference by which a DTMC is learned with far fewer samples than normal sample distribution. We exploit the concept of importance sampling, and use a mixture of samples, generated from the original system distribution and distributions that are suitably modified to produce more failures. Using the likelihood ratios of the various samples, we ensure the final trained model is faithful to the original distribution. In this way we construct accurate predictive models with orders of magnitude fewer samples. We demonstrate the gains of our approach on a file transmission protocol case study from the literature, and highlight future directions.

Neural State Classification (NSC) is a recently proposed method for runtime predictive monitoring of Hybrid Automata (HA) using deep neural networks (DNNs). NSC trains a DNN as an approximate reachability predictor that labels a given HA state x as positive if an unsafe state is reachable from x within a given time bound, and labels x as negative otherwise. NSC predictors have very high accuracy, yet are prone to prediction errors that can negatively impact reliability. To overcome this limitation, we present Neural Predictive Monitoring (NPM), a technique based on NSC and conformal prediction that complements NSC predictions with statistically sound estimates of uncertainty. This yields principled criteria for the rejection of predictions likely to be incorrect, without knowing the true reachability values. We also present an active learning method that significantly reduces both the NSC predictor’s error rate and the percentage of rejected predictions. Our approach is highly efficient, with computation times on the order of milliseconds, and effective, managing in our experimental evaluation to successfully reject almost all incorrect predictions.

Runtime enforcement and control system synthesis are two verification techniques that automate the process of transforming an erroneous system into a valid one. As both techniques can modify the behaviour of a system to prevent erroneous executions, they are both ideal for ensuring safety. In this paper, we investigate the interplay between these two techniques and identify control system synthesis as being the static counterpart to suppression-based runtime enforcement, in the context of safety properties.

We consider Runtime Verification (RV) based on Propositional Linear Temporal Logic (LTL) with both future and past temporal operators. We generalize the framework to monitor partially observable systems using models of the system under scrutiny (SUS) as assumptions for reasoning on the non-observable or future behaviors of the SUS. The observations are general predicates over the SUS, thus both static and dynamic sets of observables are supported. Furthermore, the monitors are resettable, i.e. able to evaluate any LTL property at arbitrary positions of the input trace (roughly speaking, \([\![u,i\models \varphi ]\!]\) can be evaluated for any u and i with the underlying assumptions taken into account). We present a symbolic monitoring algorithm that can be efficiently implemented using BDD. It is proven correct and the monitor can be double-checked by model checking. As a by-product, we give the first automata-based monitoring algorithm for Past-Time LTL. Beside feasibility and effectiveness of our approach, we also demonstrate that, under certain assumptions the monitors of some properties are predictive.

We study the problem of decentralized monitoring of stream runtime verification specifications. Decentralized monitoring uses distributed monitors that communicate via a synchronous network, a communication setting common in many cyber-physical systems like automotive CPSs. Previous approaches to decentralized monitoring were restricted to logics like LTL logics that provide Boolean verdicts. We solve here the decentralized monitoring problem for the more general setting of stream runtime verification. Additionally, our solution handles network topologies while previous decentralized monitoring works assumed that every pair of nodes can communicate directly. We also introduce a novel property on specifications, called decentralized efficient monitorability, that guarantees that the online monitoring can be performed with bounded resources. Finally, we report the results of an empirical evaluation of an implementation and compare the expressive power and efficiency against state-of-the-art decentralized monitoring tools like Themis.

Runtime Verification is the process of deciding whether a run of a program satisfies a given property. This work considers the more challenging problem of explaining why a run does or does not satisfy the property. We look at this problem in the context of CFTL, a low-level temporal logic. Our main contribution is a method for reconstructing representative execution paths, separating them into good and bad paths, and producing partial parse trees explaining their differences. This requires us to extend CFTL and our second contribution is a partial semantics used to identify the first violating observation in a trace. This is extended with a notion of severity of violation, allowing us to handle real-time properties sensitive to small timing variations. These techniques are implemented as an extension to the publicly available VyPR2 tool. Our work is motivated by results obtained applying VyPR2 to a web service on the CMS Experiment at CERN and initial tests produce useful explanations for realistic use cases.

Control Flow Integrity (CFI) is an effective defense technique against a variety of memory-based cyber attacks. CFI is usually enforced through software methods, which entail considerable performance overhead. Hardware-based CFI techniques can largely avoid performance overhead, but typically rely on code instrumentation, which forms a non-trivial hurdle to the application of CFI. We develop FastCFI, an FPGA based CFI system that can perform fine-grained and stateful checking without code instrumentation. We also propose an automated Verilog generation technique that facilitates fast deployment of FastCFI. Experiments on popular benchmarks confirm that FastCFI can detect fine-grained CFI violations over unmodified binaries. The measurement results show an average of 0.36% performance overhead on SPEC 2006 benchmarks.

Runtime Verification (RV) consists of analyzing execution traces using formal techniques, e.g., monitoring executions against Linear Temporal Logic (LTL) properties. Propositional LTL is, however, limited in expressiveness, as first shown by Wolper [32]. Several extensions to propositional LTL, which promote the expressive power to that of regular expressions, have therefore been proposed; however, none of which was, by and large, adopted for RV. In addition, for many practical cases, there is a need in RV to monitor properties that carry data. This problem has been addressed by numerous authors, and in previous work we addressed this by providing an algorithm that uses BDDs to represent relations over data elements. We show expressiveness deficiencies of first-order LTL and suggest an extension of (propositional as well as first-order) LTL with rules to address these limitations. We describe how the DejaVu tool is correspondingly extended and provide some experimental results.

In Runtime Verification (RV), monitoring a system means checking an execution trace of a program for satisfactions and violations of properties. The question of which properties can be effectively monitored over ideal channels has mostly been answered by prior work. However, program monitoring is often deployed for remote systems where communications may be unreliable. In this work, we address the question of what properties are monitorable over an unreliable communication channel. We describe the different types of mutations that may be introduced to an execution trace and examine their effects on program monitoring. We propose a fixed-parameter tractable algorithm for determining the immunity of a finite automaton to a trace mutation and show how it can be used to classify \(\omega \)-regular properties as monitorable over channels with that mutation.

Runtime Verification (RV) studies how to analyze execution traces of a system under observation. Stream Runtime Verification (SRV) applies stream transformations to obtain information from observed traces. Incomplete traces with information missing in gaps pose a common challenge when applying RV and SRV techniques to real-world systems as RV approaches typically require the complete trace without missing parts. This paper presents a solution to perform SRV on incomplete traces based on abstraction. We use TeSSLa as specification language for non-synchronized timed event streams and define abstract event streams representing the set of all possible traces that could have occurred during gaps in the input trace. We show how to translate a TeSSLa specification to its abstract counterpart that can propagate gaps through the transformation of the input streams and thus generate sound outputs even if the input streams contain gaps and events with imprecise values. The solution has been implemented as a set of macros for the original TeSSLa and an empirical evaluation shows the feasibility of the approach.

Cyber-physical systems (CPS) and the Internet-of-Things (IoT) result in a tremendous amount of generated, measured and recorded time-series data. Extracting temporal segments that encode patterns with useful information out of these huge amounts of data is an extremely difficult problem. We propose shape expressions as a declarative formalism for specifying, querying and extracting sophisticated temporal patterns from possibly noisy data. Shape expressions are regular expressions with arbitrary (linear, exponential, sinusoidal, etc.) shapes with parameters as atomic predicates and additional constraints on these parameters. We equip shape expressions with a novel noisy semantics that combines regular expression matching semantics with statistical regression. We characterize essential properties of the formalism and propose an efficient approximate shape expression matching procedure. We demonstrate the wide applicability of this technique on two case studies.

Runtime verification tools must correctly establish a specification’s validity or detect violations. This task is difficult, especially when the specification is given in an expressive declarative language that demands a non-trivial monitoring algorithm. We use a proof assistant to not only solve this task, but also to gain confidence in our solution. We formally verify the correctness of a monitor for metric first-order temporal logic specifications using the Isabelle/HOL proof assistant. From our formalization, we extract an executable algorithm with correctness guarantees and use differential testing to find discrepancies in the outputs of two unverified monitors for first-order specification languages.

Detection and quantification of information leaks through timing side channels are important to guarantee confidentiality. Although static analysis remains the prevalent approach for detecting timing side channels, it is computationally challenging for real-world applications. In addition, the detection techniques are usually restricted to “yes” or “no” answers. In practice, real-world applications may need to leak information about the secret. Therefore, quantification techniques are necessary to evaluate the resulting threats of information leaks. Since both problems are very difficult or impossible for static analysis techniques, we propose a dynamic analysis method. Our novel approach is to split the problem into two tasks. First, we learn a timing model of the program as a neural network. Second, we analyze the neural network to quantify information leaks. As demonstrated in our experiments, both of these tasks are feasible in practice—making the approach a significant improvement over the state-of-the-art side channel detectors and quantifiers. Our key technical contributions are (a) a neural network architecture that enables side channel discovery and (b) an MILP-based algorithm to estimate the side-channel strength. On a set of micro-benchmarks and real-world applications, we show that neural network models learn timing behaviors of programs with thousands of methods. We also show that neural networks with thousands of neurons can be efficiently analyzed to detect and quantify information leaks through timing side channels.

This paper presents an application of specification based runtime verification techniques to control mobile robots in a reactive manner. In our case study, we develop a layered control architecture where runtime monitors constructed from formal specifications are embedded into the navigation stack. We use temporal logic and regular expressions to describe safety requirements and mission specifications, respectively. An immediate benefit of our approach is that it leverages simple requirements and objectives of traditional control applications to more complex specifications in a non-intrusive and compositional way. Finally, we demonstrate a simulation of robots controlled by the proposed architecture and we discuss further extensions of our approach.

One important issue needed to be handled when applying runtime verification is the time overhead introduced by online monitors. According to how monitors are deployed with the system to be monitored, the overhead may come from the execution of monitoring logic or asynchronous communication. In this paper, we present a method for deciding how to deploy runtime monitors with awareness of minimizing the overhead. We first propose a parametric model to estimate the overhead given the prior knowledge on the distribution of incoming events and the time cost of sending a message and executing monitoring logic. Then, we will discuss how to statically decide the boundary of synchronous and asynchronous monitors such that the lowest overhead can be obtained.

We present NuRV, an extension of the nuXmv model checker for assumption-based LTL runtime verification with partial observability and resets. The tool provides some new commands for online/offline monitoring and code generations into standalone monitor code. Using the online/offline monitor, LTL properties can be verified incrementally on finite traces from the system under scrutiny. The code generation currently supports C, C++, Common Lisp and Java, and is extensible. Furthermore, from the same internal monitor automaton, the monitor can be generated into SMV modules, whose characteristics can be verified by Model Checking using nuXmv. We show the architecture, functionalities and some use scenarios of NuRV, and we compare the performance of generated monitor code (in Java) with those generated by a similar tool, RV-Monitor. We show that, using a benchmark from Dwyer’s LTL patterns, besides the capacity of generating monitors for long LTL formulae, our Java-based monitors are about 200x faster than RV-Monitor at generation-time and 2–5x faster at runtime.

AllenRV is a tool for monitoring temporal specifications, designed for ensuring good scalability in terms of size and number of formulae, and high reactivity. Its features reflect this design goal. For ensuring scalability in the number of formulae, it can simultaneously monitor a set of formulae written in past and future, next-free LTL, with some metric extensions; their efficient simultaneous monitoring is supported by a let construct allowing to share computations between formulae. For ensuring scalability in the size of formulae, it allows defining new abstractions as user-defined operators, which take discrete time boolean signals as arguments, but also constant parameters such as delays. For ensuring high reactivity, its monitoring algorithm does not require clock tick events, unlike many other tools. This is achieved by recomputing output signals both upon input signals changes and upon internally generated timeout events relative to such changes. As a consequence, monitoring remains efficient on arbitrarily fine-grained time domains.

AllenRV is implemented by extending the existing Allen language and compiler, initially targeting ubiquitous applications using binary sensors, with temporal logic operators and a comprehensive library of user-defined operators on top of them. The most complex of these operators, including a complete adaptation of Allen-logic relations as selection operators, are proven correct with respect to their defined semantics.

Thus, AllenRV offers an open platform for cooperatively developing increasingly complex libraries of high level, general or domain-specific, temporal operators and abstractions, without compromising correctness.

This article presents a benchmark generator, Timescales, which can be used to evaluate the performance and scalability of runtime verification tools using Metric Temporal Logic (MTL) formulas as their specifications. We mainly target runtime verification of cyber-physical systems and generate traces similar to the qualitative behavior of sensor readings and state variables of such systems that are observed/sampled continuously. Since such systems are composed of many heterogeneous components that work over very different time scales, it is crucial to measure the performance of the MTL monitoring tool for a wide range of timing parameters in specifications. Hence, Timescales supports the generation of benchmarks for 10 typical timed properties for any given trace length and timing parameters with several other useful features. Finally, we include some default benchmark suites generated by Timescales.
