1 Einleitung
2 Methoden
2.1 Fließrinnen und Versuchsaufbau
Variante | Versuch 1:1 | Versuch 1:5 | Buhnen | Froude Zahl | ||||
---|---|---|---|---|---|---|---|---|
Buhnenhöhe (m) | Wassertiefe (m) | Durchfluss (m3/s) | Buhnenhöhe (m) | Wassertiefe (m) | Durchfluss (m3/s) | (–)* | ||
V1 | 0,75 | 1,10 | 4,50 | 0,15 | 0,22 | 0,0805 | Überströmt | 0,25 |
V2 | 0,75 | 0,85 | 3,48 | 0,15 | 0,17 | 0,0623 | Überströmt | 0,28 |
V3 | 0,75 | 0,65 | 2,66 | 0,15 | 0,13 | 0,0476 | Nicht überströmt | 0,32 |
V4 | 0,50 | 1,10 | 4,50 | 0,10 | 0,22 | 0,0805 | Überströmt | 0,25 |
V5 | 0,25 | 1,10 | 4,50 | 0,05 | 0,22 | 0,0805 | Überströmt | 0,25 |
